Paving forms punched for dowels
dee Concrete Accessories also offers our standard line of paving forms in a punched for dowels configuration to accept rebar or solid dowels.
Paving forms punched for dowels - description
We also manufacture paving forms, punched for dowels, so these forms can be used to accept rebar or solid dowels. Paving forms are available in both 3/16" and 1/4" steel. Our paving forms punched for dowels are identical to dee's standard paving forms and reversible paving forms except for the addition of the dowel hole punching.
These forms are designed to be used when reinforced interlocking reinforced concrete is specified. The dowels, or rebar material, travel through the face of the form. After the forms are removed and adjacent concrete is placed, the two placements are interlocked by the rebar or solid dowels.
Dowel holes are punched on 2-foot centers or as specified. Dowel holes are punched slightly larger than the diameter of the solid dowels or rebar to be used allowing the paving forms to be easily slipped off the dowels after the concrete placement is complete.
All paving forms punched for dowels or rebar have a sliding nose to allow the form to be removed after placement without damaging the reinforcement material.
A less efficient alternative to using paving forms punched for dowels involves a concrete contractor placing hollow inserts into the concrete during placement or drilling dowel holes into the concrete after placement so it can receive the dowels or rebar prior to forming the adjacent placement.
Applications
dee paving forms are used in various concrete placement applications for intersections, highway entrance and exit ramps, streets, bridge approaches, airport runways, roadways, commercial driveways and truck pads, heavy equipment pads, and taper pours for ramps.
Our paving forms punched for dowels are used in those same types of applications with the additional specification requiring interlocked or reinforced concrete.
Specifications/range of sizes
Our heavy-duty, 1/4" paving forms punched for dowels are available in both standard and custom sizes. Standard punched for dowels paving form heights range from 6" to 24" with bases from 6" to 24" and are manufactured in 10' length.
Features and benefits
dee paving forms punched for dowels:
-
Allow contractors to tackle jobs that require interlocking or reinforced concrete without having to drill the placement or place inserts in the concrete during placement.
-
Increase productivity on placements requiring reinforced concrete saving time and labor expense.
-
All the reinforced concrete placements to be made with less drilling dust mess providing a healthier work environment.
Contact dee Concrete Accessories at 1-800-245-1333, fill out our contact form, or email us at info@deeconcrete.com to discuss your individual paving form needs or to identify a distributor in your area.
|
